Features：Ultra.M18,4-20mA,Cable,Diffuse
Ultrasonic sensor M18 analog. 4-20 mA 40-300 mm cable 2m, with remote teach-in by cable, AISI316L stainless steel housing, cULus
M18 cylindrical short body direct diffuse & retro-reflective Ultrasonic Sensor UK6 with Teach-In button
Nominal sensing distance：300mm
Thermal drift of Sr：≤2%
Repeat Accuracy：0,50%
Beam angle：7° ± 2°
Resolution：≤2mm
Sensitivity adjustment：Teach-in button
Hysteresis：1%
thermal compensation：Yes
Minimum sensing distance (blind zone)：40mm
Linearity error：1%
Output type：4...20mA
Switching frequency：8Hz
Response time：500ms
Operating Voltage：10 - 30Vdc
No-Load supply current：≤35mA @Val = 30V
Load current：100mA
Leakage current：10μA @ 30Vcc
Output voltage drop：2,2Vmax. @ IL=100 mA
Max ripple content：5%
LED indicators：green: echo - yellow: output
Time delay before availability：≤300ms
Dimensions：M18 x 1 / L = 46,4mm
Weight：140g
Housing Material：stainless steel AISI 316L
Connections：2m PVC Cable
Tightening torque：50Nm
Operating temperature：- 20°C…+ 70°C
Storage temperature：- 35°C…+ 80° C without freeze
Transducer Frequency：300kHz
Diameter/Dimension：M18
Degree of protection：IP67
