Product Attribute |
Attribute Value |
|
Number of Channels: |
2 Channel |
|
GBP - Gain Bandwidth Product: |
8 MHz |
|
SR - Slew Rate: |
4.5 V/us |
|
Vos - Input Offset Voltage: |
4.5 mV |
|
Ib - Input Bias Current: |
10 pA |
|
Supply Voltage - Max: |
5.5 V |
|
Supply Voltage - Min: |
2.5 V |
|
Operating Supply Current: |
1.1 mA |
|
Output Current per Channel: |
35 mA |
|
CMRR - Common Mode Rejection Ratio: |
58 dB |
|
Minimum Operating Temperature: |
- 40°C |
|
Maximum Operating Temperature: |
+ 125°C |
|
Height: |
1.65 mm (Max) |
|
Length: |
5 mm (Max) |
|
Operating Supply Voltage: |
2.5 V to 5.5 V |
|
Voltage Gain dB: |
91 dB |
|
Width: |
4 mm (Max) |
|
Unit Weight: |
0.017870 oz |
