Part no.: 1067984
Functional principle : Through-beam photoelectric sensor
Dimensions (W x H x D) : 18 mm x 18 mm x 71.5 mm
Housing design (light emission) : Cylindrical
Thread diameter (housing) : M18 x 1
Optical axis : Axial
Sensing range max. : 0 m ... 15 m
Sensing range : 0 m ... 10 m
Type of light : Visible red light
Light source : PinPoint LED
Light spot size (distance) : Ø 250 mm (10 m)
Wave length : 650 nm
Adjustment : Potentiometer
Supply voltage UB : 10 V DC ... 30 V DC
Ripple : < 5 Vpp
Current consumption : 30 mA
Switching output : PNP
Output function : Complementary
Switching mode : Light/dark switching
Signal voltage PNP HIGH/LOW : VS - (≤ 3 V) / approx. 0 V
Output current Imax. : ≤ 100 mA
Response time : < 500 µs
Switching frequency : 1,000 Hz
Photoelectric sensors
GR18
Reliable cylindrical photoelectric sensors with a wide range of application possibilities
Cylindrical photoelectric sensors from the GR18 family are characterized by their universal application possibilities, reliable object detection and a very good price-performance ratio. The sensors have a cylindrical M18 housing available either in plastic or metal. The cylindrical photoelectric sensors are also available in different housing shapes and therefore offer a high level flexibility for mounting and application options. The PinPoint LED and intelligent electronics ensure high availability of the product family. It can be used in many applications. For instance, the rugged variant in the stainless steel housing can also be used in applications where it comes into contact with chemicals and cleaning agents.
