Product Attribute |
Attribute Value |
|
Output Current: |
500 mA |
|
Number of Outputs: |
1 Output |
|
Polarity: |
Positive |
|
Input Voltage - Min: |
2.3 V |
|
Input Voltage - Max: |
5.5 V |
|
PSRR / Ripple Rejection - Typ: |
50 dB |
|
Minimum Operating Temperature: |
- 40°C |
|
Maximum Operating Temperature: |
+ 105°C |
|
Dropout Voltage: |
120 mV |
|
Dropout Voltage - Max: |
200 mV |
|
Height: |
2.3 mm |
|
Ib - Input Bias Current: |
550 uA |
|
Length: |
6.5 mm |
|
Line Regulation: |
10 mV |
|
Load Regulation: |
25 mV |
|
Output Voltage Range: |
1 V to 4 V |
|
Pd - Power Dissipation: |
1.3 W |
|
Reference Voltage: |
758 mV |
|
Voltage Regulation Accuracy: |
1 % |
|
Width: |
5.5 mm |
|
Unit Weight: |
0.011640 oz |
