In Stock ! LEUZE Single light beam safety devices MSI-SR4B-01

Brand : LEUZE
Date Code : 25+
Packing : Box
Minimum Packing : 1pcs
$0.00 $115.00
Received successfully
Coupon Code
CONTINUE SHOPPING
Discount
  • GET $10.00 OFF ON ORDERS OVER $100.00
Quantity
-
+
0 In Stock ; Ship In 48 Hours
  • LEUZE Single light beam safety devices MSI-SR4B-01
  • LEUZE Single light beam safety devices MSI-SR4B-01
  • LEUZE Single light beam safety devices MSI-SR4B-01
  • LEUZE Single light beam safety devices MSI-SR4B-01
  • LEUZE Single light beam safety devices MSI-SR4B-01
  • LEUZE Single light beam safety devices MSI-SR4B-01
  • LEUZE Single light beam safety devices MSI-SR4B-01
  • LEUZE Single light beam safety devices MSI-SR4B-01
  • LEUZE Single light beam safety devices MSI-SR4B-01
  • LEUZE Single light beam safety devices MSI-SR4B-01
1/1
  • LEUZE Single light beam safety devices MSI-SR4B-01
  • LEUZE Single light beam safety devices MSI-SR4B-01
  • LEUZE Single light beam safety devices MSI-SR4B-01
  • LEUZE Single light beam safety devices MSI-SR4B-01
  • LEUZE Single light beam safety devices MSI-SR4B-01
  • Description
Part no.: 50121918

Series : 46C
Supply voltage UB : 24 V, DC, -20 ... 20 %, Incl. residual ripple
Residual ripple : 10 %, From UB
Open-circuit current : 0 ... 15 mA
Number of digital switching outputs : 2 Piece(s)
Switching voltage high, min. : 22 V
Switching voltage low, max. : 2 V
Switching voltage, type. : 23 V
Voltage type : DC
Switching current, max. : 100 mA
Switching voltage : high: ≥(UB-2V)
low: ≤ 2 V
Switching element : Transistor, PNP
Switching principle : Dark switching
Function : Diagnostic output
Switching element : Transistor, PNP
Switching principle : Light switching
Function : Switching output
Switching frequency : 250 Hz
Response time : 2.5 ms
Readiness delay : 300 ms
Number of connections : 1 Piece(s)
Function : Signal OUT
Voltage supply
Type of connection : Cable
Cable length : 2,000 mm
Sheathing material : PUR
Number of conductors : 4 -wire
Wire cross section : 0.21 mm²
Design : Cubic
Dimension (W x H x L) : 20.5 mm x 76.3 mm x 44 mm
Housing material : Plastic
Plastic housing : PC-PBT
Lens cover material : Plastic / PMMA
Net weight : 100 g
Housing color : Red
Type of fastening : Through-hole mounting
Compatibility of materials : ECOLAB
Type of display : LED
Number of LEDs : 2 Piece(s)
Ambient temperature, operation : -30 ... 60 °C
Ambient temperature, storage : -30 ... 70 °C
Degree of protection : IP 67   IP 69K
