| Brand | Coilcraft |
| Date Code | 24+ |
| Packing | Reel |
| Package | SMD/SMT |
| Minimum Packing | 1000pcs |
Power Inductors - SMD 10uH Unshld 20% 0.8A 520mOhms
Features：
Coilcraft DO3314 Series unshielded surface-mount power inductors offer proven performance at a great value. They provide high saturation current ratings, high energy storage, and low resistance.
Open magnetic flux path
High saturation current ratings
High energy storage
Industry standard footprint
AEC-Q200 Grade 3 (−40°C to +85°C)
|
Product Attribute |
Attribute Value |
|
Package / Case: |
3.3 mm x 1.4 mm x 3.3 mm |
|
Shielding: |
Unshielded |
|
Inductance: |
10 uH |
|
Tolerance: |
20 % |
|
Maximum DC Current: |
750 mA |
|
Maximum DC Resistance: |
520 mOhms |
|
Saturation Current: |
800 mA |
|
Minimum Operating Temperature: |
- 40°C |
|
Maximum Operating Temperature: |
+ 85°C |
|
Self Resonant Frequency: |
40 MHz |
|
Termination: |
Standard |
|
Length: |
3.3 mm |
|
Width: |
3.3 mm |
|
Height: |
1.4 mm |
|
Subcategory: |
Inductors, Chokes & Coils |
|
Test Frequency: |
100 kHz |
|
Unit Weight: |
50.200 mg |
Similar Models：
DO3314-102MLC DO3314-152MLC DO3314-222MLC DO3314-332MLC DO3314-472MLC DO3314-682MLC DO3314-822MLC DO3314-103MLC DO3314-153MLC DO3314-223MLC DO3314-333MLC
