| Brand | LEUZE |
| Date Code | 23+ |
| Packing | Box |
| Package | Sensor |
| Minimum Packing | 1pcs |
Part no.: 50117373
Features：
Operating range：0 ... 6 m
Operating range：Guaranteed operating range
Operating range limit：0 ... 7.2 m
Operating range limit：Typical operating range
Light source：LED, Red
Wavelength：620 nm
LED group：1
Supply voltage UB：10 ... 30 V, DC
Residual ripple：0 ... 15 %, From UB
Open-circuit current：0 ... 18 mA
Switching frequency：500 Hz
Response time：1 ms
Readiness delay：300 ms
Function：Signal OUT Voltage supply
Type of connection：Connector
Thread size：M12
Type：Male
Material：Metal
No. of pins：4 -pin
Encoding：A-coded
Dimension (W x H x L)：15 mm x 47 mm x 32.5 mm
Housing material：Metal
Metal housing：Diecast zinc
Lens cover material：Glass
Net weight：60 g
Housing color：Silver
Retro-reflective photoelectric sensors
With reflection principle: Transmitter and receiver in the same housing, opposing reflector.
Standard models (LED and laser)
Reliable detection, even with reflective objects
Operating ranges up to 24 m
Highly accurate positioning through extremely small laser light spot
Optimized for transparent objects
Reliable detection of highly transparent objects
Operating ranges up to 6 m
Contamination compensation through integrated tracking
Optimized for reflective objects
Reliable detection of foil-wrapped, strongly scattering objects
Operating ranges up to 16 m
Sensitivity adjustable for the detection of transparent packages
Optimiert für unregelmäßige Objekte, Paletten und Polybags
Continuous detection of perforated, irregular and flat objects
Operating ranges up to 4 m
Different sensitivity levels via teach button on the device
Minimum detection height from 3 mm
