Features :
Coilcraft ZD2250/ZE2432-AE flyback transformers are designed to work with the LM5185-Q1 100 Vin PSR flyback automotive DC-DC controller from Texas Instruments. These transformers have no auxiliary winding, reducing solution size and cost while achieving greater than 90% efficiency, making them suitablefor use in isolated bias power supplies for IGBT, SiC, and GaN gate drivers.
The ZD2250/ZE2432-AE are AEC qualified, making them ideal for automotive traction inverters, onboard chargers (OBC), EV charging stations, battery management systems (BMS), automotive DC-DC converters and wide range of other automotive and industrial applications.
Designed to operate with 18 – 60 V (ZD2250) and 9 – 60 V (ZE2432) input at 200 kHz
2000 Vrms one minute isolation (hipot) primary to secondary
AEC-Q200 qualified with max part temp at 165°C
