| Brand | Coilcraft |
| Date Code | 25+ |
| Packing | Reel |
| Package | SMD/SMT |
| Minimum Packing | 2000pcs |
Features：
Our 0603LS Series wirewound ferrite beads have a ferrite core construction that provides high current handing and low DCR. Impedance ranges from 28 Ohms to 5760 Ohms at 100 MHz, and the tight inductance tolerance of ±5% is standard, stocked, and ready for shipment.
Higher performance than other surface mount ferrite beads in the market
High impedance across a wide bandwidth; up to GHz band
Ferrite construction and heavy gauge wire for high current handling
Extremely low DCR for high current applications
Eliminates high-frequency noise in power supplies or RF signal isolation applications
AEC-Q200 Grade 3 (−40°C to +85°C)
|
Product Attribute |
Attribute Value |
|
Mounting Style: |
PCB Mount |
|
Product: |
RF Inductors |
|
Product Type: |
RF Inductors - Leaded |
|
Subcategory: |
Inductors, Chokes & Coils |
|
Termination Style: |
SMD/SMT |
