Features：
Our 0906/1606 Series Micro Spring™ air core inductors have extremely high Q factors and very tight inductance tolerances, making them suitable for narrowband RF amplifier matching and tuning applications. As their name implies, air core inductors do not use a magnetic core, resulting in their high Q and the lowest possible losses for high-frequency applications. High-reliability versions are available for space, military, and other critical applications.
Inductance values from 1.65 nH to 12.55 nH (tolerances as low as 1%)
Tight tolerance can eliminate circuit tuning
Flat top for mechanical stability and reliable pick and place operations
Exceptionally high Q over a wide frequency range
Very high self resonance (up to 10 GHz)
Solder coated leads ensure reliable soldering
AEC-Q200 Grade 1 (−40°C to +125°C)
