Operational Amplifiers - Op Amps SOT23, Low-Noise, Low-Distortion, Wide-B
GBP‑Gain Bandwidth Product:42MHz
SR‑Slew Rate:10V/μs
Vos‑Input Offset Voltage:350μV
Ib‑Input Bias Current:150pA
Supply Voltage‑Max:5.5V
Supply Voltage‑Min:2.7V
Operating Supply Current:2.2mA
Output Current per Channel:48mA
CMRR‑Common Mode Rejection Ratio:90dB
en‑Input Voltage Noise Density:21nV/√Hz
Package/Case:SOIC‑8
Mounting Style:SMD/SMT
Shutdown:Shutdown
Minimum Operating Temperature:‑40℃
Maximum Operating Temperature:+125℃
Series:MAX4488
Packaging:Tube
Amplifier Type:Wideband Amplifier
Brand:Analog Devices / Maxim Integrated
In‑Input Noise Current Density:0.0005pA
Product:Operational Amplifiers
Product Type:Op Amps‑Operational Amplifiers
PSRR‑Power Supply Rejection Ratio:90dB
Subcategory:Amplifier ICs
Unit Weight:187mg
